  • DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

0 stars, based on 0reviews
Price:
$7650.00 / piece
Quantity: - + items available
Contact Us
TOPOTEK Gimbal camera

DYD20G635 is a professional 2-axis stabilization pod with 140x hybrid zoom daytime CMOS sensor, and 35mm focal length 640×512 thermal imaging sensor. This pod adopts a compact design with high stability, high integration and low power consumption. The visible light camera uses a wide dynamic sensor with 8 mega effective pixels, while the thermal adopts s a vanadium oxide detector. The system supports network RTSP picture-in-picture stream output, offers various picture-in-picture modes, multiple false color displays, and supports global temperature measurement functions. S.BUS, UART, and network can all control the camera and gimbal, and it supports local TF card recording and photography for both visible light and thermal imaging.

DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal




DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

Voltage：

   DC12～26.2V

Power：

   Dynamic 12W

Yaw Angle：

   -285°～ +285°

Pitch Angle：

   -15°～ +110°

Horizontal angle jitter：

   One-click restore to the initial position

Tilt and roll direction angle jitter：

   ±0.02°

One-Click Restore：

   ±0.03°

Adjustable Gimbal Speed：

   When the gimbal rotates, the speed is adapted based on the current speed mode and the visible light camera multiple.

DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

CMOS Size：

   1/1.8 Inch 8 mega pixel wide dynamic CMOS SENSOR

Optical Zoom：

   20x HD optical zoom lens, f=6.7～125 mm ±5%

Focusing time：

   Real time fast focusing, focusing time < 1s

Video Output：

   Network output RTSP stream, local TF card storage

Field Angle(FOV)：

    D : WIDE 66.6º±5% TELE 4.0º±5%
   H : WIDE 59.6º±5% TELE 3.5º±5%
   V : WIDE 35.7º±5% TELE 2.0º±5%


DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

Resolution ratio：

   640×512pixel

Space between pixels：

   12μm

Type：

   Uncooled vanadium oxide

Wavelength Range：

   8～14μm

Temperature measurement range：

   -20℃ ~+150℃，0~550℃

Field angle：

  35mm Lens，Field of view：12.5°x 10.0°


DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

Min tracking target size：

   16×16 pixels

Max tracking target size：

   256×256 pixels

Target Memory Time：

   2 seconds

Tracking speed：

   50 Pixel/Frame max

Simultaneous detection qty：

   100 targets max

Recognized categories：

   Human and Vehicle

Min detection target size：

   32×32 pixels

Debounce：

   Dynamic stabilization


DYD20G635 High Performance Dual Sensor Gimbal 20X Optical Zoom+35mm 640×512 Thermal

Dimensions：

   φ130mm*182.4mm

Operating Environment：

   -10℃ to +55℃ / 20% to 80% RH

Storage Condition：

   -20℃ to +60℃ / 20% to 95% RH

Weight：

   988±20g
