TOPOTEK Gimbal cameraDHU662G613P-E is a dual-sensor camera system integrated 1080P prime lens visible light and 13mm 640×512 thermal imaging, with a high-precision professional 3-axis stabilized gimbal. It supports both IP network and HDMI dual output, the gimbal uses a high-precision encoder FOC control scheme, it has the characteristics of high stability, small size, light weight, and low power consumption. the visible light camera uses a wide dynamic sensor with an effective 2 mega pixel. Both Serial Port ①, S.BUS, and network can be used to control the camera and gimbal, and it supports local TF card dual-channel recording and photography.
| Voltage： |
DC 12V-26.2V/td>
| Power： |
Static 4.6W |
| Pitch Angle action range： |
-45°～ +100° |
Yaw Angle action range： |
-145°～ +145° |
| Roll Angle action range： |
-45°～ +45° |
Angle jitter in pitch and roll directions： |
±0.02° |
| Horizontal angle jitter： |
±0.03° |
One-click return function： |
One-click automatic quick return to the initial position |
| Gimbal control speed adjustable： |
The speed adaption is carried out based on the current speed mode and the multiple of the visible light camera |
Control mode： |
Support network IP control ,serial port and S.BUS control
|
| CMOS Size： |
1/2.8 inch 2.4 million pixels Wide dynamic range CMOS SENSOR |
| Digital zoom ： |
Support 9x digital zoom |
| Video Output： |
Network HD RTSP output 1080P, video stream local TF storage |
| Field Angle(FOV)： |
6mm lens FOV：49.8°× 29.3°
|
| Network support mode： |
1080P 30 fps |
| HDMI support mode： |
Micro-D HDMI 1080P 60fps |
| Resolution ratio： |
640×512 pixel |
| Space between pixels： |
12μm |
| Type： |
Uncooled focal plane microbolometer |
| Wavelength Range： |
8～14μm |
| Thermal sensitivity(NETD)： |
≤50mk@F1.0
|
| Field Angle： |
9.1mm Lens; FOV：32.9°×26.6°
|
| Measurement (Optional)： |
Support global temperature measurement, optional full pixel temperature saving function
|
| Min tracking target size： |
16×16 pixels |
Max tracking target size： |
256×256 pixels |
| Target Memory Time： |
2 seconds |
Tracking speed： |
50 Pixel/Frame max |
| Simultaneous detection qty： |
100 targets max |
Recognized categories： |
Human and Vehicle |
| Min detection target size： |
32×32 pixels |
Debounce： |
Dynamic stabilization |
| Dimensions： |
115mm × 85mm |
Working Condition： |
-10℃ to +60℃ |
| Stored Environment： |
-20℃ to +80℃ |
Weight： |
245±10 g |
