TOPOTEK Gimbal camera

  • DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

0 stars, based on 0reviews
Price:
$6222.00 / piece
Quantity: - + 999items available
Contact Us
TOPOTEK Gimbal camera

DHU10G619 is an integrated dual sensor camera system which features a 10x optical zoom CMOS sensor with 9x digital zoom (a total of 90x hybrid zoom), a 19mm focal length 640*512 uncooled thermal imaging sensor with 9x digital zoom and a professional high-precision three-axis stabilization gimbal. It uses ethernet IP output and IP control. The gimbal uses a high-precision encoder FOC control scheme, which has the characteristics of high stability, small size, light weight, and low power consumption. The visible light camera uses an 2 million effective pixel wide dynamic CMOS sensor. The thermal imaging uses a 640x512 resolution vanadium oxide detector. The system supports network RTSP picture-in-picture stream output, supports multiple picture-in-picture modes, multiple pseudo-color displays, and global temperature measurement functions. Both the serial port① and the network can control the camera and the gimbal, and it supports local micro-sd card dual-channel video recording and photography.

DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera


DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

Voltage：

   DC 12V-26V

Power：

   Dynamic 6.5W

Roll Angle：

   -45°~+45°

Pitch Angle：

   -45°~+100°

Yaw Angle：

   -140°～ +140°

The amount of angular jitter in pitch and roll direction：

   ±0.02°

The amount of horizontal Angle jitter：

   ±0.03°

One-Click Restore：

   One-click automatic quick return to the initial position

The speed of the gimbal control is adjustable：

   The speed adaption is carried out based on the current speed mode and the multiple of the visible light camera

Control mode：

   Support network IP control, SBUS control, serial port control (optional PWM control)

DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

CMOS Size：

   1/2.8 inch 2 megapixel CMOS SENSOR

Optical zoom ：

   10x optical zoom lens, f=5.15±5%～47.38±5%mm

focusing time：

   Real-time fast focusing function, focusing time <1S

Video output：

   Ethernet RTSP output 1080P, storage in micro-sd card

Field Angle(FOV)：

   D : WIDE 69.5º±5% TELE 7.95º±5%
  H : WIDE 61.5º±5% TELE 7.00º±5%
  V : WIDE 35.0º±5% TELE 3.97º±5%

Network support mode：

   1080P 30 fps

HDMI support mode：

   Micro-D HDMI 1080P 60fps


DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

Resolution ratio：

   640×512 pixel

Space between pixels：

   12μm

Type：

   Uncooled vanadium oxide

Wavelength Range：

   8～14μm

Thermal sensitivity(NETD)：

   ≤50mk@25℃@F1.0

Field of view：

   19mm camera lens, FOV：22.9°×18.4°

Measurement function (optional)：

   Central point, the highest temperature and lowest temperature display temperature function; Supports global temperature measurement


DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

Min tracking target size：

   16×16 pixels

Max tracking target size：

   256×256 pixels

Target Memory Time：

   2 seconds

Tracking speed：

   50 Pixel/Frame max

Simultaneous detection qty：

   100 targets max

Recognized categories：

   Human and Vehicle

Min detection target size：

   32×32 pixels

Debounce：

   Dynamic stabilization


DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera

Dimensions：

   φ:126mm H:123mm

Oerating Environment：

   -10℃ to +55℃ / 20% to 80% RH

Storage Conditions ：

   -20℃ to +60℃ / 20% to 95% RH

Weight：

   370±10g




DHU10G619 10x visible light Optical zoom camera + 640*512 thermal dual light camera
