TOPOTEK Gimbal camera

  • DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

0 stars, based on 0reviews
Price:
$1821.00 / piece
Quantity: - + 999items available
Contact Us
TOPOTEK Gimbal camera

DHU03 is a single light integrated system with 3x optical zoom and high-precision professional three-axis stab gimbal. It adopts HDMI&IP output, and the adopts high precision encoder FOC control scheme, which has the characteristics of high stability, small size, light weight and low power consumption. The zoom visible light camera adopts a SENSOR with an effective pixel count of 48 million; The system supports network RTSP stream output. Network, serial port① and S.BUS, and can control the camera andPTZ, and support local TF storage.



DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output




DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

Voltage：

   DC12V-26.2V

Power：

   Dynamic 6W

Roll angle action range：

   -45°～ +45°

Pitch angle action range：

   -130°～ +30

Yaw angle action range：

   -150°～ +150°

Pitch and Roll Jitter Angle：

   ±0.02°

Horizontal Jitter Angle：

   ±0.03°

One-Click Restore：

   One-click restore to the initial position

Pan- tilt control speed is adjustable：

   When the pan-tilt rotates, the speed is adaptive based on the current speed mode and the multiple of the visible light camera

Control mode：

   Support network IP control, SBUS control, serial port control(Optional PWM control)


DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

SENSOR：

   1/2 inch 48 megapixel CMOS SENSOR

Optical Zoom：

   3x High definition optical zoom lens, 15mm(Wide)-50mm(Tele)±5%

Digital zoom：

   9x digital zoom

Focusing time：

   Real time fast focusing function, focusing time<1s

Field Angle (FOV)：

   D : WIDE 28.98º±3% TELE 9.06º±3%

  H : WIDE 23.48º±3% TELE 7.29º±3%

  V : WIDE 17.81º±3% TELE 5.49º±3%

Video output：

   Network high-definition RTSP output 1080P, video stream local TF storage


DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

Device Size：

    110mm×90mm

Work Condition：

   -10℃ to +45℃ / 20% to 80% RH

Storage Condition：

   -20℃ to +60℃ / 20% to 95% RH

Weight (Not including dampers)

   210±10g


DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output

Min tracking target size：

   16×16 pixels

Max tracking target size：

   256×256 pixels

Target Memory Time：

   2 seconds

Tracking speed：

   50 Pixel/Frame max

Simultaneous detection qty：

   100 targets max

Recognized categories：

   Human and Vehicle

Min detection target size：

   32×32 pixels

Debounce：

   Dynamic stabilization





DHU03-E 48MP Million Pixels 3-Axis Single light Gimbal, HDMI&IP output
